FLEX NEON LED 20W/M (RGB) – 16X16MM
SKU: LCLS24VFLX-16X16-TV-20W-RGB-30K
💡 Available in 5 m (16.4 ft) or 10 m (32.8 ft) reels
The FLEX NEON 16X16MM – TOP VIEW RGB-30K from LEDCO delivers diffused LED lighting upward (top view) in a large 16x16mm format, engineered for architectural and event applications demanding maximum visual impact. Its XL flexible neon profile ensures continuous, intense, hotspot-free light diffusion.
Operating at 24V DC with a power draw of 20W/m, this RGB+30K flex neon combines dynamic colours (red, green, blue) and warm white 3000K in a single reel — switching from a colourful accent mood to functional white lighting with one product. Available in 5m or 10m reels.
Recommended Applications
- Commercial storefronts and restaurants — RGB accent
- Suspended ceilings, gypsum reveals and XL cornices
- Game rooms, home theatres and residential bars
- Events, stages and temporary installations
- Display windows and illuminated signage
Performance and Installation
Its IP66 rating allows installation in covered damp environments — pergolas, balconies, gazebos. cULus certified, compliant with Canadian and US electrical standards. Rated lifespan up to 50,000 hours.
Power Supply Calculation
This flex neon draws approximately 6.10 watts per foot (20W/m). Multiply the total length in feet by 6.10 then add a 20% safety margin.
Example: 10 m (32.8 ft) × 6.10 = 200W → add 20% = 240W driver minimum. Use a 24V driver sized to the total calculated wattage.
RGB + 30K Control
This flex neon uses a 5-pin (RGB+W) connector. To take full advantage of the colour modes and white dimming, use a dedicated RGBW controller:
- RGBW controller + RF receiver — remote or mobile-app control, up to 100 ft range
- 4-channel RGBW receiver — installed between the driver and the flex neon to manage several independent zones
Complete your installation with the dedicated accessories:
