LED POWER SUPPLY - 5IN1 - 96W

The 5-in-1 dimmable LED power supply 96W by LEDCO is a professional constant voltage driver offering five dimming modes in a single IP67 waterproof enclosure. Designed for demanding indoor and outdoor installations, it combines the versatility of five dimming protocols with the ruggedness of a dust- and water-resistant housing.

5 DIMMING MODES IN A SINGLE DRIVER

This 5-in-1 dimmable LED driver supports five dimming protocols, making it compatible with virtually any lighting control system on the market:

• TRIAC: Compatible with standard in-wall dimmers (leading edge and trailing edge), the most common mode for residential use.
• 0-10V: The most common standard in commercial and institutional lighting.
• 1-10V: Compatible with European systems and industrial controllers.
• 10V PWM: For digital pulse-width modulation controllers.
• Resistance: Potentiometer dimming for simple, cost-effective control.

This multi-protocol compatibility eliminates the need to select a different driver depending on the control system used. Whether for a residential project with a TRIAC wall dimmer or a commercial installation controlled via 0-10V, a single model covers all scenarios.

TECHNICAL SPECIFICATIONS

This waterproof 96W LED power supply operates on 24V DC with an IP67 protection rating, ensuring full resistance to dust and temporary water immersion. Its aluminum housing provides efficient heat dissipation even in challenging environments.

To ensure optimal lifespan, it is recommended not to exceed 80% of total capacity, meaning a maximum load of 76.8W. This translates to approximately 8 meters of 9.6W/m LED strip or 4 meters of 19.2W/m strip.

RECOMMENDED APPLICATIONS

This power supply is compatible with all of our LED strips, LED puck lights and fixtures operating on 24V DC. Thanks to its IP67 rating and multi-protocol compatibility, it is particularly suited for:

• Outdoor and landscape lighting requiring a waterproof, dimmable power source (soffits, decks, facades).
• Commercial projects with 0-10V control systems such as offices, conference rooms and retail spaces.
• Wet-location installations including bathrooms, spas, commercial kitchens and industrial environments.
• Residential projects with wall dimmers thanks to the built-in TRIAC mode, offering the same installation simplicity as a standard dimmable driver with the added benefit of IP67 waterproofing.

For installations requiring more power with the same dimming protocols and multiple outputs, check out the 5-in-1 192W and 5-in-1 288W multi-output models. For indoor projects that do not require IP67 waterproofing, explore our standard dimmable LED power supplies. Contact our team at (450) 444-4007 or visit our showroom in Saint-Hubert, on Montreal's South Shore.
